Aluminum Nitride Plate Sheet Disc

Aluminum Nitride Plate Sheet Disc

Purity: 95%-99%

  • Custom sizes and standard sizes in stock
  • Competitive Price
  • Quick Lead Time

  • Aluminum nitride plates, sheets, and discs are high-performance ceramic materials with exceptional thermal conductivity, electrical insulation, and high-temperature resistance. They are widely used in electronic heat dissipation, semiconductor equipment, and other high-temperature industries. As a leading supplier and manufacturer of premium aluminum nitride products, we can provide high-quality aluminum nitride plates, sheets, and discs in a variety of specifications at competitive prices, offering customized solutions to meet specific requirements.
Get A Quote

Or email us at sales@heegermaterials.com.

Aluminum nitride plate/sheet/disc data sheet

Reference code:

HM1918

Purity:

95%-99%

Density:

3.32 g/ cm³

Appearance:

Dark gray / Light gray / Beige

Aluminum nitride plate/sheet/disc

Aluminum nitride sheets/plates/discs have a coefficient of thermal expansion similar to silicon, allowing them to adapt perfectly to electronic modules during temperature changes. Thanks to their excellent electrical insulation and dielectric properties, aluminum nitride sheets/plates/discs are ideal for large-scale integrated circuits or high-power modules. Manufactured through a high-temperature die-casting and sintering process, they are characterized by zero porosity, excellent flatness, and surface smoothness. Advanced Ceramics Hub can supply customized solutions in width, length, thickness, and surface finish to meet diverse industrial and research requirements.

Aluminum nitride plate/sheet/disc Advantages

  • High thermal conductivity (170-230 W/mK), up to 9.5 times that of alumina.
  • A thermal expansion coefficient similar to that of silicon (Si).
  • Superior electrical insulation and lower dielectric constant.
  • Higher mechanical strength (450 MPa).
  • Excellent resistance to molten metal corrosion.
  • High purity and non-toxic.

Applications of aluminum nitride plates/sheets/discs

  • Thermal management : Heat dissipation for power electronics, LEDs and lasers.
  • Substrates for power electronics : Power semiconductors, such as electric vehicle chargers.
  • High frequency and microwave devices : Improved performance of RF and microwave components.
  • High-temperature applications : Aerospace, automotive electronics, and sensors.
  • Lasers and optoelectronic devices : Heat dissipation in lasers.
  • Thermal Management Techniques
    Thermal Management Techniques
  • Electric and Electrical Equipments HM
    Electrical and Electronic Area
  • Automobile industry HM
    automobile industry
  • Aerospace Applications HM
    Aerospace

Aluminum Nitride Material Properties

Property

Unit

HMAN1000

HMAN2000

HMAN3000

HMAN4000

HMAN1000S

Density

g/cm3

3.32

3.32

3.32

3.30

3.30

Young’s Modulus

GPa

 300-350

300-350

300-350

300-350

350

Fracture Toughness KIC

MPa m1/2

3

3

3

2.5

3

Poisson’s Ratio

–

 0.22

0.22

0.22

0.22

0.22

Compressive Strength

MPa

3000

3000

3000

3000

3000

Flexural Strength @ 25°C

MPa

350

350

350

350

350

Hardness

GPa

10

10

10

12

11

Property

Unit

HMAN1000

HMAN2000

HMAN3000

HMAN4000

HMAN1000S

Thermal Conductivity @ 25°C

W/mK

170

200

230

200

170

CTE 25°C ➞ 400°C

10-6/K

4.5

4.5

4.5

3.5

4.6

Max Temperature (Air)

°C

1200

1200

1200

1200

1200

Max Temperature (Inert)

°C

1200

1200

1200

1200

1200

Property

Unit

HMAN1000

HMAN2000

HMAN3000

HMAN4000

HMAN1000S

Dielectric Constant

1 MHz

8.8

8.8

8.5

8.5

8.8

Dielectric Loss

1 MHz

5×10-4

5×10-4

5×10-4

5×10-4

5×10-4

Dielectric Strength DC @ 25°C

kV/mm

15

15

15

15

14

Volume Resistivity @ 25°C

ohm-cm

 >1013

>1013

>1013

 >1014

 >1014

Aluminum Nitride Material Grades

HMAN1000 is our standard high purity aluminium nitride with a thermal conductivity of 170 W/mK. This is the same thermal performance as our substrate material but offers the possibility of larger pieces in length/width and in thicknesses up to 30mm.
HMAN1000 has good coefficient of thermal expansion – matched to silicon and gallium nitride over wide temperature ranges.

HMAN100 Applications:

  • High power insulators
  • Laser components
  • Water cooled heatsinks
  • Power electronics
  • Aerospace, medical and semiconductor components

HMAN1000S 170 W/mK is our standard high thermal conductivity substrate material, However, other high-performance grades are also available.

HMAN1000S Applications:

  • Heat sinks
  • Heat spreaders
  • Laser heatsinks power rectifiers
  • Aerospace, power electronics, rectifiers

HMAN2000 is one of our enhanced grades of aluminium nitride, offering all the mechanical performance of HMAN1000 with the enhanced benefits of 200 W/mK thermal conductance.

HMAN2000 Applications:

  • Heat sinks
  • Heat spreaders
  • Laser heatsinks power rectifiers
  • Aerospace, power electronics, rectifiers

HMAN3000 is one of our enhanced grades of aluminium nitride offering, all the mechanical performance of HMAN1000 with the enhanced benefits of 230 W/mK thermal conductance.

HMAN3000 Applications:

  • Heat sinks
  • Heat spreaders
  • Laser heatsinks power rectifiers
  • Aerospace, power electronics, rectifiers

HMAN4000 is one of our enhanced grades of aluminium nitride offering, all the mechanical performance of HMAN1000 with the enhanced benefits of 200 W/mK thermal conductance.

HMAN4000 Applications:

  • Heat sinks
  • Heat spreaders
  • Laser heatsinks power rectifiers
  • Aerospace, power electronics, rectifiers

Aluminum Nitride Ceramic Machining

Ceramic Machining HM

Aluminum Nitride (AlN) ceramic machining is a precise process used to fabricate high-performance components from aluminum nitride materials. Machining aluminum nitride ceramics requires specialized equipment and techniques to handle their brittleness and hardness. Proper tooling and controlled environments are essential to avoid material damage and achieve the desired surface finish and dimensional accuracy. The common machining methods are as follows:

  • Diamond Cutting: Diamond tools are used to achieve fine precision and smooth surface finishes, ideal for complex shapes.
  • Laser Cutting: A non-contact method used for intricate shapes, with high precision and minimal thermal impact.
  • Precision Grinding: Utilized to achieve fine tolerances and surface finishes. Requires special care to prevent cracking or chipping due to the ceramic’s brittleness.
  • Wire EDM (Electrical Discharge Machining): A method often used for intricate cutting, especially for thin and complex geometries.

Aluminum Nitride Ceramic Packaging

Aluminum Nitride Ceramic products are typically packaged in vacuum-sealed bags to prevent moisture or contamination and wrapped with foam to cushion vibrations and impacts during transport, ensuring the quality of products in their original condition.

ceramic products packing HM

Download

Get A Quote

We will check and get back to you in 24 hours

ToTo customize your aluminum nitride plate, aluminum nitride sheet, or aluminum nitride disc, please provide the following details:

  1. Dimensions : Length, width, diameter, and thickness.
  2. Material quality : Specify the material grades.
  3. Purity  of the material
  4. Tolerances : Specify the tolerances you can accept.
  5. Surface finish:  polished, rough, etc.
  6. Quantity  of the products you need
  7. Alternatively, you can provide a  drawing  with your specifications.

Once we have this information, we will be able to provide you with a quote within 24 hours.

We carry a wide variety of boron nitride products in stock, and for these, there is generally no minimum order requirement. However, for custom orders, we typically set a minimum order value of $200. The lead time for stock items is usually 1-2 weeks, while custom orders usually take 3-4 weeks, depending on the specifics of the order.

Aluminum Nitride is a high-performance inorganic ceramic material with excellent thermal conductivity and electrical insulation properties. It is a common ceramic material used in various electrical devices. It is also resistant to the corrosion of most molten metals, such as copper, lithium, aluminum, etc.

  • High Thermal Conductivity: Over 170 W/mK, close to BeO and SiC, more than five times higher than alumina (Al2O3).
  • Thermal Expansion Coefficient: 4.5 × 10⁻⁶°C, similar to silicon (3.5-4 × 10⁻⁶°C).
  • Good Light Transmittance: Excellent transparency properties.
  • Non-Toxic: Safe and environmentally friendly.
  • Excellent Electrical Properties: Includes dielectric constant, dielectric loss, volume resistivity, and dielectric strength, making it an outstanding insulator.
  • Good Mechanical Properties: Higher flexural strength than alumina (Al2O3) and beryllium oxide (BeO), widely used in industrial applications.
