Silicon Carbide Properties: Hardness, Thermal Conductivity & Uses

In 2025, silicon carbide (SiC) stands out as a high-performance ceramic material revolutionizing industries like electronics, automotive, and aerospace. Renowned for its exceptional hardness (9–9.5 on Mohs scale), superior thermal conductivity (100–400 W/m·K), and remarkable durability in extreme conditions, SiC enables cutting-edge applications from power electronics to turbine blades. This blog explores SiC’s key properties—hardness and thermal conductivity—and their transformative impact on diverse, high-demand applications, offering insights for engineers and innovators looking to harness its potential.

At Advanced Ceramics Hub, we specialize in high-quality silicon carbide ceramics, ensuring optimal performance for industrial and scientific applications.

What Is Silicon Carbide (SiC)?

Silicon carbide (SiC) is a high-performance ceramic compound of silicon and carbon, known for its covalent crystal structure, typically hexagonal (e.g., 4H-SiC, 6H-SiC) or cubic (3C-SiC). Synthesized primarily via the Acheson process, SiC is rarely found in nature as Moissanite. Its exceptional hardness (9–9.5 Mohs), thermal stability (up to 2700°C), and chemical inertness make it ideal for extreme conditions in electronics, automotive, and aerospace applications

Key Characteristics of Silicon Carbide:

✅ Extreme Hardness (9.5 on the Mohs scale, close to diamond).
✅ High Thermal Conductivity (3x better than silicon).
✅ Wide Bandgap Semiconductor (3.2 eV vs. silicon’s 1.1 eV).
✅ Chemical & Thermal Stability (withstands temperatures up to 1,600°C+).
✅ Resistance to Radiation & Wear (ideal for harsh environments).

What Are The Types of Silicon Carbide?

Silicon carbide exists in multiple forms, each with distinct properties tailored for specific applications. Here’s a detailed breakdown of the major types:

1. By Crystal Structure (Polytypes)

These differ in atomic stacking sequences, affecting electronic and thermal properties:

Polytype	Bandgap (eV)	Thermal Conductivity (W/m·K)	Key Applications
3C-SiC (Cubic)	2.3	360	MEMS sensors, early semiconductor research
4H-SiC (Hexagonal)	3.2	370-490	Power electronics, EV inverters (most commercial use)
6H-SiC (Hexagonal)	3.0	320-400	LED substrates, high-temperature sensors
15R-SiC (Rhombohedral)	2.9	200-300	Specialized optoelectronics

2. By Manufacturing Process

A. Single-Crystal SiC:

Grown via PVT (Physical Vapor Transport) or CVD (Chemical Vapor Deposition)
Used for: Semiconductor wafers, high-end power devices
Cost: $$$$ (Expensive due to slow growth rates)

B. Polycrystalline SiC

Sintered SiC: Powder processed at high temps (~2,000°C)

Grades: SSiC (Sintered), LPS-SiC (Liquid Phase Sintered)
Uses: Industrial nozzles, armor plates, abrasives

Reaction-Bonded SiC (RB-SiC)

Infiltrated with silicon (10-20% Si remaining)
Pros: Lower cost, complex shapes possible
Cons: Slightly reduced thermal/mechanical properties

C. CVD SiC

Ultra-pure, near-theoretical density
Applications: Telescope mirrors, semiconductor equipment parts

3. By Electrical Properties

Type	Resistivity (Ω·cm)	Key Feature
Conductive SiC	0.1-10	Doped with N (n-type) or Al (p-type) for power devices
Semi-insulating SiC	>10⁵	Minimizes RF losses (5G/6G base stations)

4. Specialized Forms

SiC Foam: Porous structure for filters/catalysts
SiC Fiber: Reinforced composites (jet engines)
SiC Nanoparticles: Additives for advanced lubricants

Which Type to Choose?

Application	Recommended Type	Why?
EV Power Modules	4H-SiC wafers	Highest efficiency at high voltages
Industrial Nozzles	Good performance at a lower cost	Best wear resistance
Space Optics	CVD SiC	Near-zero thermal expansion
Cost-sensitive Parts	RB-SiC	Good performance at lower cost

The Hardness of Silicon Carbide (SiC): Why It’s Exceptional

Silicon carbide (SiC) is renowned for its exceptional hardness, achieving 9–9.5 on the Mohs scale and approximately 2500–2800 HV (Vickers Hardness), making it one of the hardest materials, surpassed only by diamond and cubic boron nitride. Compared to other ceramics like alumina, metals like hardened steel, or advanced materials like tungsten carbide, SiC’s superior resistance to wear and abrasion makes it ideal for demanding applications such as cutting tools, grinding wheels, and protective armor. Its ability to withstand mechanical stress and abrasive environments ensures long-lasting performance, driving innovation in industries like aerospace for precision machining and defense for lightweight armor.

1. How Hard Is Silicon Carbide?

Mohs Hardness: 9.5 (Diamond = 10, Tungsten Carbide = 9).
Knoop Hardness: 2,480–3,200 kgf/mm² (compared to ~700 for steel).
Vickers Hardness: ~3,000 HV (3x harder than quartz).

2. Why Is SiC So Hard?

Crystal Structure: Covalently bonded silicon-carbon tetrahedra form an ultra-rigid lattice.
Strong Atomic Bonds: Si-C bonds are shorter and stronger than Si-Si (silicon) or C-C (graphite).

3. SiC vs. Other Hard Materials

Material	Mohs Hardness	Vickers Hardness (HV)	Wear Resistance	Typical Applications
Silicon Carbide	9–9.5	2500–2800	Cutting tools, armor, and grinding wheels	Cutting tools, armor, grinding wheels
Alumina	9	1800–2000	Good	Ceramic components, insulators
Hardened Steel	5–6.5	600–900	Moderate	Machinery, tools
Cubic Boron Nitride	9.5–10	4500–5000	Superior	Precision machining, superabrasives
Tungsten Carbide	8.5–9	1800–2400	Very Good	Drill bits, cutting tools
Diamond	10	7000–10000	Unmatched	Precision cutting, drilling

Looking for top-quality silicon carbide products? Explore Advanced Ceramics Hub’s selection.

Thermal Conductivity of Silicon Carbide (SiC): The Ultimate Heat Dissipator

Silicon carbide (SiC) is a standout material for thermal management, offering high thermal conductivity ranging from 100 to 400 W/m·K, depending on its polymorph (e.g., 4H-SiC, 6H-SiC) and processing conditions. This exceptional ability to dissipate heat positions SiC as a critical component in high-temperature environments, outperforming many ceramics and rivaling some metals. In 2025, SiC’s thermal conductivity drives its widespread use in power electronics, such as MOSFETs and Schottky diodes, where efficient heat dissipation enhances performance and reliability. Its advantages also extend to aerospace, enabling components like turbine blades to operate under extreme heat, and automotive applications, such as EV inverters, where thermal stability reduces energy losses. SiC’s combination of high thermal conductivity and thermal stability makes it indispensable for cutting-edge thermal management solutions.

Material	Thermal Conductivity (W/m·K)
4H-SiC (Single Crystal)	370-490
6H-SiC (Single Crystal)	320-400
Polycrystalline SiC	120-200
Reaction-Bonded SiC	80-120
Silicon (Si)	~150
Copper (Cu)	~400

Why SiC Excels at Heat Dissipation

Three fundamental reasons:

Atomic Bond Strength: Ultra-strong Si-C covalent bonds (shorter than Si-Si bonds) enable efficient phonon transport
Crystal Structure Advantages: Hexagonal lattice (4H/6H-SiC) provides optimal phonon pathways
Low atomic mass difference between Si and C atoms minimizes phonon scattering
Temperature Resilience: Maintains high conductivity even at 1,600°C+ (metals like copper degrade rapidly

SiC’s Thermal Properties Vs. Other Materials

Material	Thermal Conductivity (W/m·K)	Max Operating Temp (°C)	Applications
Silicon Carbide	100–400 (type-dependent)	~2700	Power electronics, turbine blades
Alumina	20–30	~1700	Insulators, substrates
Copper	350–400	~1085 (melting point)	Heat sinks, wiring
Diamond	2000–2500	~3500	High-end thermal management

Discover our high-quality silicon carbide products.

Other Key Properties of Silicon Carbide (SiC)

While SiC is famous for its extreme hardness and thermal management capabilities, its full suite of properties makes it truly unique. Here are the other critical characteristics that define its performance:

1. Electrical Properties

Property	Value	Significance
Bandgap	3.2 eV (4H-SiC)	Enables high-voltage, high-temperature operation
Breakdown Field	2-4 MV/cm	10x higher than silicon → more compact power devices
Electron Mobility	900 cm²/V·s (4H-SiC)	Supports high-frequency switching
Saturation Velocity	2×10⁷ cm/s	Faster than silicon for RF applications

2. Chemical Stability

Property	Performance	Real-World Impact
Oxidation Resistance	Forms protective SiO₂ layer at 1,200°C+	Survives harsh environments
Acid/Alkali Resistance	Inert to most acids (except HF)	Ideal for chemical processing equipment
Corrosion Resistance	Outperforms stainless steel in salt spray tests	Marine and offshore applications

3. Mechanical Properties

Property	Value	Comparison
Flexural Strength	300-600 MPa	Comparable to tungsten carbide
Elastic Modulus	400-450 GPa	4x stiffer than steel
Fracture Toughness	3-4 MPa·m¹/²	More brittle than metals but tougher than alumina

4. Nuclear Properties

Attribute	Performance	Implication
Neutron Absorption	Low cross-section	Fusion reactor components
Radiation Hardness	Withstands 100x more dose than silicon	Space electronics
Swelling Resistance	Minimal under irradiation	Nuclear fuel cladding

Property Comparison: SiC vs. Competing Materials

Property	SiC	AlN	Al₂O₃	Si
Thermal Conductivity	★★★★★	★★★★☆	★★☆☆☆	★★★☆☆
Electrical Resistivity	Adjustable	Insulator	Insulator	Semiconductor
Chemical Resistance	★★★★★	★★★☆☆	★★★★☆	★★☆☆☆
Cost	$$$	$$$$	$	$$

Why These Properties Matter Today

EV Revolution: SiC’s electrical+thermal combo enables 800V battery systems
5G Deployment: Semi-insulating SiC substrates reduce RF losses
Green Hydrogen: SiC pumps handle corrosive electrolytes
Space Tech: Radiation-hard SiC electronics for lunar/Mars missions

Request a custom quote for top-quality silicon carbide products.

Silicon Carbide (SiC) Applications: Powering the Future with Extreme Performance

Silicon carbide’s unique combination of properties has made it indispensable across multiple high-tech industries. Here’s a comprehensive breakdown of its most impactful applications:

1. Power Electronics Revolution

EV Power Systems (Tesla, BYD, Porsche Taycan)

Inverters: 10% higher efficiency than silicon IGBTs
On-board chargers: 3x faster charging
DC-DC converters: 50% size reduction

Renewable Energy

Solar inverters (5% more energy harvested)
Wind turbine converters

Industrial Drives

30% energy savings in motor controllers

2. Extreme Environment Electronics

Application	SiC Advantage
Aerospace (Jet engine sensors)	Operates at 600°C+
Oil/Gas (Downhole electronics)	Withstands 20k psi + corrosive fluids
Nuclear (Reactor monitoring)	Radiation-hardened

3. Industrial & Mechanical Systems

Wear Components:

Pump seals (10x lifespan vs. tungsten carbide)
Sandblasting nozzles
Ball bearing races

High-Temperature Tools:

Kiln furniture (1600°C capability)
Semiconductor wafer boats

4. Defense & Aerospace

Component	Benefit
Missile nose cones	Survives Mach 5+ friction
Armor plating	30% lighter than steel with the same protection
Radar systems	Handles 10x higher power density

5. Optoelectronics & Quantum Tech

UV detectors: Solar-blind sensors for flame detection
High-power LEDs: First blue LEDs used SiC substrates
Quantum computing: Silicon vacancies as qubits

6. Emerging Applications

Wireless Power Transfer:

EV charging pads (95% efficiency at 11kW)
Medical implant charging

5G/6G Infrastructure:

GaN-on-SiC RF devices (base stations)
40% better heat dissipation than silicon

Fusion Energy:

Plasma-facing components in ITER
Divertor tiles withstand 10MW/m² heat flux

Why Industries Are Switching to SiC?

Energy Savings: 100M tons CO₂ reduction possible by 2030 in EVs alone
System Miniaturization: 70% smaller power modules
Reliability: 10x longer lifespan in harsh conditions

The SiC Application Matrix

Industry	Current Use	Future Potential
Automotive	Inverters, chargers	48V systems, wireless charging
Energy Grid	HVDC converters	Solid-state transformers
Space	Satellite power	Nuclear propulsion systems
Manufacturing	Cutting tools	Additive manufacturing beds

Did You Know? The new Porsche 800V platform uses SiC to add 100km of range in just 5 minutes of charging.

Silicon carbide (SiC) stands as a cornerstone of innovation in 2025, driven by its exceptional hardness (9–9.5 Mohs), high thermal conductivity (100–400 W/m·K), and chemical inertness. These properties enable SiC to excel in demanding applications, from power electronics in 5G and renewable energy systems to durable aerospace components and EV inverters, delivering unmatched efficiency and longevity. As industries strive for high-performance, sustainable solutions, SiC’s role continues to expand, reshaping electronics, automotive, and aerospace landscapes.

Would you like details on implementing SiC in a specific application? Contact us today!
